E10-300A


The P Audio E10-300A is a high performance wide bandwidth transducer optimized for use in mid bass frequencies. The E10-300A is an upgraded design that features many of P Audio's new technologies and performance upgrades. The 10 inch (254mm) diameter piston will produce extremely high sound pressure levels at both low and mid band frequencies and is ideal for high level response in both live sound and recorded music venues. The transducer uses high energy ferrite based magnetics to achieve a very high acoustic output to weight ratio. TheE10-300A has been optimized for use in two way or three way sound reinforcement systems and has an operating range of 50Hz to 5000Hz.

The E10-300A features a large 3 inch diameter voice coil that provides and AES rated 300 watts of continuos power handling and a full 1200 watts of peak rated power handling when sufficient amplifier headroom is available. The E10-300A utilizes P Audio's Auto Balanced Cooling (ABC) technology to not only improve transducer power handling and reliability but to also increase power compression performance by carefully balancing and directing airflow to critical areas.

The voice coil design is a bobbin wound geometry with P Audio's edge wound rectangular wire technology to improve conversion efficiency and provide a large cross-sectional area for superior cooling.

The transducer chassis is a die cast aluminum design that insures a very high degree of structural integrity.

GENERAL SPECIFICATIONS

  Nominal diameter   254 mm/10in
  Power rating   300 W(AES)
  Nominal impedance   8Ω
  Sensitivity   93 dB
  Frequency range   50-3500 Hz
  Chassis type   Die Cast
  Magnet type   Ferrite
  Magnet weight   1.41 kg/49.7 oz
  Voice coil diameter   76.2 mm/3 in
  Coil material   CCA-W
  Former material   Kapton
  Cone material   Paper
  Surround material   Cloth
  Suspension   Single
  X-max   4.1 mm/0.16 in
  Gap depth   8 mm/0.31 in
  Voice coil winding width   16.2 mm/0.64 in
  Packing dimension WxDxH (mm)   270 x 270 x 145
  Net weight   4.8 kg/10.58 lb
  Shipping weight   5.1 kg/11.24 lb

FEATURES

  • 3" Voice Coil
  • 1200 Watts Peak Power Handling
  • Ferrite Magnetics
  • Precision Rectangular Ribbon Wire Geometry
  • Die Cast Aluminum Chassis

SMALL SIGNAL PARAMETERS

  Re   5.9Ω
  Fs   73 Hz
  Mms   38.1 g/1.34 oz
  Mmd   34.13 g/1.2 oz
  Qms   6.37
  Qes   0.65
  Qts   0.59
  Vas   23.44 lt/0.83 ft3
  BI   12.59 Tm
  Cms   1.3e-04 m/N
  Rms   2.74 Ns/m
  Le (at 1kHz)   0.49 mH
